ZL18 Wheel Loader
  • ZL18 Wheel Loader
  • Loading 1800KG Wheel Loader
  • ZL18 Wheel Loader
  • Wheeled Loader

ZL18 Wheel Loader, Loading 1800KG Wheel Loader

Go back to Catalog: Wheel Loader

Package: Pallet Packing or as customer requier

Minimum Order: 1 SET

Delivery Time: 15 Days - 30Days

Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

By wheel: 2WD/4WD

Color : Green, Red, Blue, on request

Payment Terms: T/T, L/C At Sight

Contact Us
ZL18 Wheel Loader Series
Detailed Description of ZL-18
Engine Details Model: Xichai 4102/ Weichai4102/Xinchai498(Euro3)/Dongfeng cummins
Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
Rated Power: 53KW/47kw/36.8kw/60kw
Rated Speed: 2200 r/min (rpm)
Fuel Consumption ratio in standard working condition: 243g/kw.h
Transmission System Torque Converter Model YJ280
Gear Box Model YJB152 YJB152A
Type:  Fixed-spindle Power shift
Shift gear control oil pressure:  1.2-1.5MPa
Rated input speed:  2500 (rpm)
Speed Gear Shift 2 Forward Shift, 2 Reverse Shift
Max Speed 24km/h
Bucket Bucket Capacity: 0.8 m3
Bucket width: 1620mm
Bucket type: Heavy-duty bolt on teeth
Overall   Dimensions Max. Breakout Force: ≥45
Rated Load: 1800kg
Operating Weight: 4600kg
(1) Overall Length (Bucket on ground position):  5100mm
Overall Height (a) Ground to Cab Top: 2720mm
(b) Ground to exhaust pipe: It is below from the top of cabin
(c) Dumping Height: 2800/3100mm/4300
Overall Width: 2200mm
Operating   Specifications Steering System:  Articulated Frame with hydraulic power steering
Min Turning Radius:  4800mm
Driving System:  Hydraulic converter
Operation Weight 4500kg
Brake System Tyre Size 16/70-20
Service Brake: Four Wheel Hydraulic spread-shoed brake
Parking Brake:  Hand operated
7.0 Wheelbase: 1400mm
8.0 Track:  2005mm
9.0 Function of leveling automatically------YES
