ZL15 Wheel Loader
  • ZL15 Wheel Loader
  • Farming Wheel Loader
  • Wheeled Loader
  • China Wheel Loader

ZL15 Wheel Loader, 1500KG Wheel Loader

Go back to Catalog: Wheel Loader

Package: Pallet Packing or as customer requier

Minimum Order: 1 SET

Delivery Time: 15 Days - 30Days

Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

By wheel: 2WD/4WD

Color : Green, Red, Blue, on request

Payment Terms: T/T, L/C At Sight

Contact Us
ZL15 Wheel Loader Series
Mini loader with CE certificate
Euro 3 standard engine
Larger space's cab
Powerful driving foce
Main Specification for ZL-15
Model ZL15
Rated load(kg) 1500
Bucket capacity(m3) 0.7
Wheel distance(mm) 1330
Axle-base(mm) 2200
Loader clearance radius(mm) 4600
Mini base to the ground(mm) 310
Dump clearance(mm) 2700
Distance acc. to the height(mm) 900
Time of raise(s) 4
Hydraulic cycle time(s) 8.5
Turns to pick the strength mose greatly(kn) 45
Drive ways four are drive
Torque Converter Model YJ240
Gear Shift 2 forward & 2 reverse shift
Tyresize 14-17.5
Operating weight(kg) 3500
Overall dimensions(mm) 5000*1700*2700
Engine model Xinchai 498
Engine Type Four strokes, Water cooling, Inline, injecting combustion chamber
Cylinder No. -Bore*Stroke(mm) 4-102*115
Engine rated power(kw) 36.8
Engine rated output(rpm) 2400
