WH704 Tractor
  • WH704 Tractor

WH704 Tractor

Go back to Catalog: WH Tractor

Package: Pallet Packing or as customer requier

Minimum Order: 1 SET

Delivery Time: 15 Days - 30Days

Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

By wheel: 2WD/4WD

Color : Green, Red, Blue, on request

Payment Terms: T/T, L/C At Sight

Contact Us
WH704 Tractor Series
Model  WH504 WH604 WH704 WH804 HW904
Type   4×4 Wheeled Type   4×4 Wheeled Type   4×4 Wheeled Type   4×4 Wheeled Type   4×4 Wheeled Type
Dimensions
of Tractor
(mm)
Length 3700 3700 3900 3900 4000
Width 1710 1710 1795 1795 1900
Height 2160 2160 2300 2300 2610
Tread Front Wheel 1250 1250 1300 1300 1300
Rear Wheel 1200,1300(usual),1400 1200,1300(usual),1400 1200,1300(usual),1400 1200,1300(usual),1400 1200,1300(usual),1400
 Wheel Base 1950 1950 2072 2072 2072
Min. Ground Base 325(the bottom of steering horizontal pulling rod) 390(the bottom of steering horizontal pulling rod)
Min. Usage Mass (kg) 2500 2500 2700 2700 2750
 Engine Model quanchai495 quanchai4105 quanchai4108 quanchai4108 quanchai4110
Type Vertical, water cooled and 4-stroke
Rated Power(kw)  36.8 44.1 51.4 58.8 66.2
Rated Rev.(r/min) 2300 2400 2400 2300 2300
Fuel  Diesel Oil Diesel Oil Diesel Oil Diesel Oil Diesel Oil
Tire  Front Wheel 8.3-20 8.3-20 8.3-24 8.3-24 8.3-24
Rear Wheel 12.4-28 12.4-28 14.9-30 14.9-30 14.9-30
 Clutch dry-friction, single disc and two stage
 Steering  Hydraulic type
Transmission Box two shafts, 4×(3+3) composed
 Suspension Type Post Positioned Tri-point Suspension Catalogue I
PTO
Type and Rev.(r/min)
Post-position, half-independent,
540/760 or 540/1000(optional)
                  Spline Size I38 Rectangle Spline with 8 teeth
