10HP Walking Tractor
  • 10HP Walking Tractor
  • 10HP Walking Tractor with Plough
  • Power Tiller
  • Walk-behind Tractor

10HP Walking Tractor, Hand Tracor, Two Wheel Walk-behind Tractor

Go back to Catalog: Walking Tractor

Package: Pallet Packing or as customer requier

Minimum Order: 1 SET

Delivery Time: 15 Days - 30Days

Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

By wheel: 2WD/4WD

Color : Green, Red, Blue, on request

Payment Terms: T/T, L/C At Sight

Contact Us
10HP Walking Tractor Series





Engine

Pattern
Vertical, One Cylinder, Four Stroke, Diesel powered, Water-cooled
Model 1105
Displacement(L) 1.194
Oil Consumption
(g/ km. h)
  < 320
Engine Oil Consumption                    (g/ km. h) <   2.72
Rated Power(kw) 13.23
Rated Speed(rpm) 2000








Machine Parameters

Type Pull and Drive
Overall Size(mm) 2680*960*1250(without seat)
Wheel Tread(mm) 800
Minimum Ground Clearance(mm) 185
Minimum Turning Radius(m) 0.9
Structural Weight(kg) 360 (with connecting frame), 480(with rotary tiller)
Tyre 6.00-12
Theoretical Speed (km/h) Forward: 1.4, 2.5, 4.1, 5.3, 9.4, 15.3
Reverse: 1.0, 3.8
Rated Traction(N) 2400
Gearbox (3+1 ) × 2
Oil Type 0# in summer, -10 or 20 in winter
Cooling Type Evaporation
Rear-Wheel Diameter (mm) 340
